Ayzeze: Safely charging your e-bike or e-scooter
• Don’t leave your battery unattended while charging, when you're out or while you're asleep
• Don’t cover chargers or battery packs when charging
• Don’t overload sockets or use unsuitable extension chords
• Don’t charge or store batteries in direct sunlight or in areas with temperatures above 45⁰C
• Don’t charge batteries next to combustible materials or hazardous substances
• Always unplug your charger once you have finished charging
• Always make sure to only use the proper proprietary charger
• Always ask a professional when converting your e-bike or e-scooter
• Always check your battery (and charger) for visible damage
-----
Frame material: Aluminum alloy
Painting colors: black red, silver white
Tire size: 26 x 4.0 inches all terrain fat tire
Motor power: 48V 500W
Motor torque: 65 N · m
Battery configuration: 48V18Ah (Dongci 21700 battery cells)
Charging time: 8-9 hours (54.6V 2A charger)
Braking system: Hydraulic disc brake (disc: 160mm)
Transmission system: Shimano 1 × 7-speed
Dashboard: LCD screen (supports Bluetooth connection to DUOTTS APP)
Maximum speed: Factory speed limit: 25 km/h (adjustable to 50 km/h)
Maximum range: Pure electric mode: 40-45 km Power assist mode: 80-90 km
Maximum climbing angle: 30 °
Maximum load capacity: 150 kg
Recommended height: 170-200 cm
Adjustable seat cushion height: approximately 87-104 cm
Handlebar specification aluminum alloy, length 72 cm
Waterproof rating: IPX4 (splash proof)
The net weight/gross weight of the product is approximately 34.81 kg/approximately 45.16 kg
Product size: 1930 × 720 × 1180 mm
Packaging size: 1550 × 300 × 830 mm
Core selling point extraction
1. Conqueror of all terrains, fearless of any road conditions
26 × 4.0-inch ultra wide fat tire: provides a huge grip area and buoyancy, easily crushing extreme terrains such as sand, snow, mud, etc., truly achieving all road conditions.
65N · m super strong torque: The 500W motor unleashes powerful low torque, allowing for a smooth start even on 30 ° steep slopes, with power readily available.
Professional grade variable speed brake: Shimano 7-speed transmission combined with front and rear hydraulic disc brakes provides precise control and strong and stable braking performance.
2. Intelligent dual-mode endurance, worry free mileage
90 kilometer ultra long power assisted range: The 48V 18Ah high-capacity battery (using automotive grade Dongci 21700 battery cells) can achieve amazing range in power assisted mode, meeting the needs of long-distance exploration.
Intelligent APP interconnection: Supports connecting to DUOTTS APP to achieve intelligent control such as vehicle status monitoring, data recording, remote settings, etc., comprehensively upgrading the riding experience.
3. Luxury configuration and comfortable experience
All aluminum alloy lightweight body: While ensuring the durability of the frame, it effectively controls the overall weight of the vehicle.
Adjustable seat cushion and wide body handlebars: The seat cushion height can be adjusted within a wide range (87-104cm), coupled with 72cm wide aluminum alloy handlebars, ensuring a comfortable and stable riding posture.
Complete factory accessories: standard with air pump, phone bag, complete set of tools, etc., ready to use out of the box, worry free and effortless.
4. Performance beast, balancing compliance and freedom
Dual mode speed: The factory default speed is 25km/h, which complies with regulations. At the same time, an APP speed release function is provided, which can be unlocked to a top speed of 50km/h to meet performance requirements in different scenarios.
High load capacity and wide range adaptation: With a maximum load capacity of 150kg, it is suitable for users with a height of 170-200cm, meeting the usage needs of the vast majority of adult males.
one-sentence summary
This electric bicycle is a performance beast that combines "all terrain passability, ultra long intelligent range, and luxurious comfort configuration". Its powerful torque, professional variable speed braking system, and APP interconnection function can not only meet the conquering desire of extreme terrain, but also provide a comfortable and intelligent urban commuting experience. It is a high-end vehicle tailored for outdoor explorers and urban cycling players.
